Key Features for Commercial Flake Ice Makers:

Unmatched Ice Purity and Texture

Indulge in the pure pleasure of crystal-clear ice that melts slowly, preserving your beverages’ flavors. Our flake ice maker produces perfectly textured ice flakes that are soft, chewable, and quick to cool, making them ideal for various applications.

Versatile Cooling Solutions

Whether you run a restaurant, bar, or seafood market, or need ice for medical purposes, our commercial flake ice maker is the ultimate solution. The flexible design allows it to adapt to different environments, providing precise cooling for food displays, salad bars, seafood storage, and more.

Energy-Efficient Performance

With increasing concerns about energy consumption, our commercial flake ice maker is designed with efficiency in mind. By utilizing advanced technology, it maximizes ice production while minimizing energy waste, ensuring you have a cost-effective and environmentally friendly solution.

Customizable Options

Every business has unique requirements, and we offer customizable options to cater to your specific needs. From different capacities to specialized features, our commercial flake ice maker can be tailored to suit your operational demands, ensuring a perfect fit for your establishment.



Model	Compressor Power	Daily Output	Ref. Capacity (Kcal)	Evaporator Temp. (°C)	Condensor Temp. (°C)	Total Power (Kw)	Cooling Mode	Power supply	Refrigerant	N.W (KG)	Unit Dimension L×W×H (mm)	Bin Size L×W×H (mm)
H03TF	2HP	0.3T/24H	1290	-22	40	1.49	Air Cooling	1P/220V/50Hz	R22	165	780×760×690	780×905×920
H05TF	3HP	0.5T/24H	2580	-22	40	2.37	Air Cooling	3P/380V/50Hz	R404A	215	1100×820×740	1100×960×1070
H1TF	5HP	1T/24H	5160	-22	40	4.11	Air Cooling	3P/380V/50Hz	R404A	242	1100×820×840	1100×960×1070
H1.5TF	9HP	1.5T/24H	7740	-22	40	7.29	Air Cooling	3P/380V/50Hz	R404A	360	1310×970×1005	1310×1260×1050
H2TF	10HP	2T/24H	10320	-22	40	8.31	Air Cooling	3P/380V/50Hz	R404A	440	1500×1095×1050	1500×1350×1150
H2.5TF	13HP	2.5T/24H	12900	-22	40	9.22	Air Cooling	3P/380V/50Hz	R404A	510	1500×1095×1200	1500×1350×1150
H3TF	15HP	3T/24H	15480	-22	40	11.59	Air Cooling	3P/380V/50Hz	R404A	560	1750×1190×1410	1750×1480×1290

• Small commercial flake ice machine is widely used in significant chain supermarkets, hotel chilling, seafood market, food processing, vegetable preservation, and other industries.
• The ice production capacity of small commercial flake ice machine ranges from 0.3T/24H to 3T/24H
• The parts used in the refrigeration unit are all from the United States, Germany, Japan, and other countries with leading refrigeration technology
• The control system adopts fully automatic microcomputer control, through PLC programmable controller to start and stop the ice machine automatically, so that the mechanical operation system of the ice bucket and the water supply circulation system is coordinated and matched to achieve safe and efficient operation.
• The entire ice-making process of the ice maker is equipped with computer intelligent control such as water shortage, full ice, high and low voltage alarm, phase sequence protection, overload protection, and so on. When the unit fails, the PLC automatically shuts down for protection and displays the status of the fault indicator on the input point. When the fault recovers, the PLC receives the information and automatically starts the unit, realizing fully automatic control.

Remarks:

• The standard cooling method is air cooling. Water cooling can be made upon request.
• Standard working conditions: ambient temperature 25°C, water supply temperature 15°C, evaporation temperature -22°C, condensation temperature 40°C
